The LP8860DQVFPRQ1 is an automotive high efficiency LED driver with a boost controller. It has 4 high precision can be controlled by PWM input signal, SPI or I/O. The driver can be controlled by PWM input signal, SPI or I2C master or both. It can be controlled by PWM input signals, SPI or I/O. The boost converter has adaptive output signals, SPI or I2C master control, or both. The boost converter has adaptive output voltage control with adaptive output voltage control by the headroom voltage of the current sink. This feature minimises power consumption by adjusting the voltage to a level that is sufficient under all conditions. A wide range of adjustable frequencies allows the LP8860DQVFPRQ1 to avoid interference from the AM radio band.The LP8860DQVFPRQ1 supports built-in hybrid PWM and current dimming, which reduces EMI, prolongs the life of the LEDs, and increases the total optical power, and phase-shifted PWM to reduce noise and output ripple.

Product Attributes

Type: DC DC Controller

Topology: Boost

Internal Switch: None

Number of Outputs: 4

Voltage - Supply (minimum): 3V

Voltage - Supply (Max): 48V

Voltage - Output: 48V

Current - Output/Channel: 150mA

Frequency: 100kHz ~ 2.2MHz

Dimming: PWM

Operating Temperature: -40°C ~ 125°C (TA)

Mounting Type: Surface Mount

Package/Housing: 32-PowerLQFP

Supplier Device Package: 32-HLQFP (7x7)

Applications

• Backlighting for

• Automotive infotainment systems

• Automotive dashboards

• Smart mirrors

• Head-Up Display (HUD)

• Central Information Display (CID)

• Audio Video Navigation (AVN)
