The DS25BR150TSD is a single-channel 3.125 Gbps LVDS buffer/transceiver optimised for high-speed signal transmission, suitable for data communication between PCB boards and balanced cables. The device is packaged in an 8-WSON (3×3mm) package and integrates 100Ω input/output termination resistors to reduce signal reflection and echo loss while simplifying PCB layout complexity.

DS25BR150TSD Features

• Low jitter, high noise immunity, and low power consumption operation from DC to 3.125 Gbps

• On-chip 100Ω input and output termination minimises insertion loss and return loss, reduces component count, and minimises PCB space

• 7 kV electrostatic discharge protection on LVDS I/O pins protects adjacent components

• Compact 3 mm x 3 mm WSON-8 space-saving package

DS25BR150TSD Product Attributes

Manufacturer: Texas Instruments

Product Type: LVDS Interface Integrated Circuit

Type: LVDS

Number of Drivers: 1 Driver

Number of Receivers: 1 Receiver

Data Rate: 3125 Mb/s

Input Type: CML, LVDS, LVPECL

Output Type: LVDS

Supply Voltage - Maximum: 3.6 V

Minimum Supply Voltage:    3 V

Minimum Operating Temperature:    -40°C

Maximum Operating Temperature:    +85°C

Mounting Style:    SMD/SMT

Package/Enclosure:    WSON-8

Application Areas

• Clock or Data Buffering/Repeating

• OC-48/STM-16 Clock or Data Buffering/Repeating

• InfiniBand

• FireWire
