REF3040AIDBZR is a precision, low-power, low-dropout voltage reference product packaged in a miniature 3-pin SOT-23 package. REF3040AIDBZR is a performance-enhanced version of the REF30 series, specifically designed for precision applications.

REF3040AIDBZR features low power consumption and improved accuracy, making it ideal for loop-powered industrial applications (such as pressure and temperature transmitters) as well as battery-powered applications. The REF3040AIDBZR is rated for industrial-grade operating temperatures ranging from –40°C to +125°C. The REF3040AIDBZR is easy to use in intrinsically safe and explosion-proof applications, as it does not require a load capacitor to maintain stability.

REF3040AIDBZR Product Attributes

Reference Type: Series

Output Type: Fixed

Voltage - Output (Minimum/Fixed): 4.096V

Current - Output: 25 mA

Tolerance: ±0.2%

Temperature Coefficient: 75ppm/°C

Noise - 0.1Hz to 10Hz: 45µVp-p

Noise - 10 Hz to 10 Hz: 128 µVrms

Voltage - Input: 4.146 V to 5.5 V

Current - Supply: 50 µA

Operating Temperature: -40°C to 125°C (TA)

Mounting Type: Surface Mount

Package/Housing: TO-236-3, SC-59, SOT-23-3

Supplier Device Package: SOT-23-3

REF3040AIDBZR Applications

• Field transmitters and sensors

• Solar energy

• PLC, DCS, and PAC

• Energy storage systems

• Healthcare

• AC inverters and variable frequency drives

• Handheld test equipment
