TLD1120EL: 360mA, LITIX™ - Automotive LED Driver, PG-SSOP-14

Model: TLD1120EL

Package: PG-SSOP-14

Type: Automotive LED Driver

Overview:

The LITIX TM base TLD1120EL is a single-channel high-side driver IC with an integrated output stage. The device is designed to control LEDs with currents up to 360 mA. In a typical automotive application, the device is capable of driving three red LEDs with currents up to 180 mA, with current capability limited by thermal cooling.  Output current control is virtually independent of load and supply voltage variations.

TLD1120EL Features:

Single-channel device with integrated output stage (current source) optimised for driving LEDs

Output current up to 360mA

Low current consumption in sleep mode

Supports PWM operation via VS and EN pins

Output current is regulated by an external low-power resistor, which can be connected to a PTC resistor to protect the LEDs in case of over-temperature conditions

Reverse polarity protection

Overload protection

Undervoltage detection

Wide temperature range: -40 °C < T j < 150 °C

PG-SSOP14 heatsink package

TLD1120EL Applications:

Designed for exterior LED lighting applications such as taillights/brake lights, turn signals, marker lights, side lights

This device is also particularly suitable for interior LED lighting applications such as ambient lighting, interior lighting and instrument panel lighting.
