The TPS2064CDGN-2 is a high-performance dual-channel current-limited power switch IC designed for applications requiring precise current control and high reliability. The chip supports an operating voltage range of 4.5V to 5.5V, with each channel capable of handling up to 1.5A of load current, featuring fast overcurrent response and low on-resistance (typical value of 70mΩ).

Features of the TPS2064CDGN-2

• Dual power switch series

• Rated currents of 0.5A, 1A, 1.5A, and 2A

• Current limit tolerance accuracy of ±20%

• Fast overcurrent response - 2µs (typical)

• 70mΩ (typical) high-side N-channel metal-oxide-semiconductor field-effect transistor (MOSFET)

• Operating voltage range: 4.5V to 5.5V

• Spike pulse fault reporting (FLTx)

• Components with (TPS20xxC) and without (TPS20xxC-2) output discharge

• Reverse current blocking

• Built-in soft start

• Compatible with existing

• Operating temperature range: -40°C to 85°C

Technical specifications of the TPS2064CDGN-2

Operating voltage range: 4.5V to 5.5V

Maximum output current: 1.5A per channel

On-resistance: 70mΩ (typical)

Overcurrent response time: 2µs (typical)

Package type: 8-pin HVSSOP

Operating temperature range: -40°C to +125°C

Application areas for the TPS2064CDGN-2

• USB ports/hubs, laptops, desktop computers

• High-definition digital televisions

• Set-top boxes

• Short-circuit protection functionality
