The OPA607IDCKR device is a decompensated general-purpose CMOS operational amplifier with a minimum stable gain of 6V/V, featuring low noise of 3.8nV/√Hz and a GBW of 50MHz. The OPA607IDCKR device combines low noise and high bandwidth, making it ideal for general-purpose applications requiring a good balance between cost and performance. The high-impedance CMOS inputs make the OPA607IDCKR amplifier suitable for connecting to sensors with high output impedance (e.g., piezoelectric sensors).

OPA607IDCKR Features

• Gain-bandwidth product (GBW): 50MHz

• Quiescent current: 900µA (typical)

• Wideband noise: 3.8nV/√Hz

• Input temperature drift: 1.5 μV/°C (maximum)

• Offset voltage: 120 µV (typical)

• Input bias current: 10 pA (maximum)

• Rail-to-rail output (RRO)

• Decompensated gain ≥ 6 V/V (stable)

• Shutdown current: 1 µA (maximum)

• Supply voltage range: 2.2V to 5.5V

OPA607IDCKR Specifications

• Amplifier type: CMOS

• Number of circuits: Single

• Output type: Rail-to-rail

• Slew rate: 24V/μs

• Gain-bandwidth product: 50MHz

• Input bias current: 3pA

• Input offset voltage: 120 μV

• Supply current: 900 μA

• Output current: 60 mA

• Package Type: SC-70-6 (SOT-363)

OPA607IDCKR Applications

• Current sensing

• Fish finders and sonar

• Ultrasonic flow meters

• Gardening and power tools

• Printers

• Light curtains and safety devices

• Optical modules

• Handheld test equipment

• PM2.5 and PM10 particle sensors
