Each channel of the TPS92830QPWRQ1 can set the channel current independently through the sense resistor value. An internal precision constant current regulation loop senses the channel current from the voltage across the sense resistor and controls the gate voltage of the N-channel MOSFET accordingly. The device also incorporates a two-stage charge pump for low dropout operation. The charge pump voltage is high enough to support a variety of N-channel MOSFETs.

Functional Features

● AEC-Q100 compliance

● Device temperature class 1: Ambient operating temperature range of -40°C to 125°C

● Human Body Discharge Model (HBM) Electrostatic Discharge (ESD) Classification Level H2

● Device Component Charging Model (CDM) ESD classification level C4B

● Wide input voltage range of 4.5 V to 40 V

● 3-channel high-level and current-sense current converter

● Individual channel current settings

● Independent channel PWM inputs

● PWM dimming via PWM input and power supply

● EMC-optimised slew rate

● High-precision LED driver

● Precision current control with external N-channel MOSFETs (2.5 tolerance)

● 20:1 analogue dimming configuration with built-in Bin resistor support

● Precision PWM generator with full duty cycle shielding (2% tolerance)

● Open-bit PWM output for synchronisation

Applications

● Rear lights - taillights and parking lights, rear turn signals, fog lights, reverse lights

● Headlights - position lights, daytime running lights, front turn indicators, reverse lights, low beams
