The UCC25710DWR is an LLC half-bridge controller specifically designed for multi-string LED lighting, featuring advanced current-mode control technology and offering low power consumption, high efficiency, and high power density. It provides closed-loop LED string current control, supports PWM dimming input, and features adjustable FMIN and FMAX, making it suitable for a wide range of indoor and outdoor lighting applications.

UCC25710DWR Features

• Closed-loop LED string current control

• Pulse Width Modulation (PWM) dimming input

• Adjustable FMIN (accuracy of 3%) and FMAX (accuracy of 7.5%)

• LLC and series LED dimming switch control

• Programmable dimming LLC on/off transition to eliminate audible noise

• Closed-loop current control at low dimming duty cycles

• Programmable soft start

• Precise VREF for strict output regulation

• Overvoltage, undervoltage, and input overcurrent protection with automatic restart response

• Two-stage overcurrent threshold with lockout response

• 400mA/800mA gate drive current

• Low startup and operating current

• Lead-free (Pb), 20-pin, SOIC package

Technical specifications: UCC25710DWR

Mounting method: Surface mount

Number of pins: 20

Package: SOIC-20

Input voltage range: 11V - 18V

Number of output interfaces: 1

Operating temperature range: -40°C to +125°C

Dimming method: PWM dimming

UCC25710DWR Applications

• Suitable for LED backlighting in LCD televisions and monitors

• LED general lighting
