The OPA2191IDR is a low-power, 36V, e-trim™ CMOS precision operational amplifier introduced by Texas Instruments, packaged in an SOIC-8 package, and part of the OPAx191 series (including the OPA191, OPA2191, and OPA4191). This chip features ultra-low offset voltage, high common-mode rejection ratio (CMRR), and rail-to-rail input/output (RRIO) characteristics, making it widely applicable in industrial control, medical equipment, high-precision instruments, and audio systems.

OPA2191IDR Core Features

• Dual CMOS inputs with 1 kHz noise as low as 15 nV/√Hz

• Ultra-low offset voltage: typical ±5 µV, maximum ±25 µV

• Ultra-low drift: ±0.1 µV/°C (typical), with excellent long-term stability

• Rail-to-rail input/output, allowing signals to swing to the power supply rails, enhancing dynamic range

• Wide power supply range: single supply 4.5 V to 36 V, dual supply ±2.25 V to ±18 V

• Low quiescent current: 140 µA per channel, suitable for battery-powered or power-constrained systems

• High common-mode rejection: 140 dB; open-loop gain 145 dB; PSRR 130 dB

• Bandwidth: 2.5 MHz GBW; slew rate 5 V/µs; capable of driving a 1 nF capacitive load stably

• EMI/RFI filtered input terminals, enhancing immunity to interference in harsh industrial environments

• Package: 8-pin SOIC (tape and reel)

OPA2191IDR Applications

• Analogue input modules

• Mixed-signal modules (AI, AO, DI, DO)

• Data acquisition (DAQ)

• Source measurement units (SMU)

• Pressure transmitters

• Train control and management systems

• Laboratory and field instruments
