The OPA2196IDGKR is a dual-channel, low-noise, zero-drift precision operational amplifier introduced by Texas Instruments (TI), packaged in an 8-pin VSSOP (DGK) package. Operating voltage range: 4.5 V – 36 V (single supply) or ±2.25 V – ±18 V (dual supply). Features rail-to-rail output and MUX-friendly input structure, capable of directly driving high-precision ADCs, suitable for industrial and automotive-grade high-reliability applications.

OPA2196IDGKR Features

• Zero-drift architecture: 25 µV maximum input offset voltage, temperature drift of 0.5 µV/°C

• Ultra-low input bias: 5 pA (typical)

• High common-mode rejection: 140 dB

• Gain bandwidth: 2.5 MHz, slew rate of 7 V/µs

• Low noise: 15 nV/√Hz @ 1 kHz

• Rail-to-rail output, 65 mA output current per channel

• Low quiescent current: 140 µA per channel

• Operating temperature: -40 °C to +125 °C, compliant with AEC-Q100 (automotive grade)

OPA2196IDGKR Specifications

Supply voltage: 4.5 V – 36 V (single) / ±2.25 V – ±18 V (dual)

Input offset voltage: 25 µV (maximum)

Input bias current: 5 pA

Gain-bandwidth product: 2.5 MHz

Slew rate: 7 V/µs

Output Type: Rail-to-Rail

Package: 8-VSSOP (3 mm × 3 mm)

Number of Channels: 2

Operating Temperature: -40 °C to +125 °C

OPA2196IDGKR Applications

• Multiplexed data acquisition systems

• Test and measurement equipment

• High-resolution analogue-to-digital converter (ADC) driver amplifiers

• SAR ADC reference buffer

• Analogue input and output modules

• High-side and low-side current sensing

• High-precision comparators

• Medical instruments
