The INA2134UA is a dual-channel differential line receiver designed specifically for high-performance audio systems. It features integrated precision laser-trimmed resistors and high-speed operational amplifiers with a fixed gain of 0 dB (1 V/V), enabling easy balanced-to-unbalanced conversion and significantly suppressing common-mode noise. The device is packaged in a 14-SOIC package and is suitable for professional audio, broadcasting equipment, and high-end consumer audio products.

INA2134UA Features

• Dual-channel independent differential amplifiers with extremely low channel crosstalk

• Fixed gain of 0 dB (1 V/V), eliminating the need for external gain resistors

• Ultra-low distortion: 0.0005% (typical at 1 kHz)

• High slew rate: 14 V/µs, ensuring fast dynamic response

• High common-mode rejection ratio: 90 dB (typical), effectively eliminating noise interference

• Wide supply voltage range: ±4 V to ±18 V (single supply 8 V to 36 V)

• Low quiescent current: 2.4 mA per channel (typical)

• Full temperature industrial grade: -40 °C to +85 °C

INA2134UA Specifications

Number of channels: 2 channels

Fixed gain: 1 V

Input offset voltage: 1 mV

Input impedance (differential): 50 kΩ

Common-mode rejection ratio (CMRR): 90 dB (minimum 74 dB)

Bandwidth (-3 dB): 3.1 MHz

Output swing: Rail-to-rail

Supply voltage range: ±4 to ±18 V or 8 to 36 V

Package: 14-SOIC (3.9 mm wide)

Operating Temperature: -40 to +85    °C

Applications

• Audio differential line receiver

• Overlay amplifier

• Unit-gain inverting amplifier

• Dummy ground generator

• Instrument module

• Current shunt monitor

• Voltage-controlled current source

• Ground loop eliminator
