Trade Name:Audio Amplifier
Brand:TI
Particular Year:22+
Package:SSOP-28
Delivery Date:New and Original
Stock: 15000pcs
The PGA2500IDB is a digitally controlled analogue microphone preamplifier designed specifically for the front end of high-performance audio analogue-to-digital (A/D) converters. Key features of the PGA2500IDB include low noise, wide dynamic range, and differential signal paths. The chip's built-in DC servo loop minimises DC offset, while the common-mode servo function can be used to enhance common-mode rejection ratio.
The PGA2500IDB offers a gain range of 10dB to 65dB (1dB per step) and includes a unity gain setting. The wide gain range enables the PGA2500IDB to be used with a variety of microphones. Gain settings and internal functions are programmed via a 16-bit control word, which can be loaded through a simple serial port interface. The serial data output pin supports daisy-chain connection of multiple PGA2500IDB devices. Four programmable digital outputs are provided for controlling external input pad switching, phantom power, high-pass filter, and polarity reversal functions. The PGA2500IDB requires +5V and -5V power supplies and is housed in a compact SSOP-28 package.
PGA2500IDB Features
Fully differential input-to-output architecture
Digital gain control via serial port interface:
Gain range: 10dB to 65dB, in 1dB steps
Unit gain (0dB) can be set via the serial port or dedicated control pin
Dynamic performance:
Equivalent noise (ZS = 150 and gain = 30dB): –128dBu
Total harmonic distortion plus noise (THD+N) at gain = 30dB: 0.0004%
Zero-crossing detection minimises audible distortion during gain switching
Integrated DC servo minimises output bias voltage
Common-mode servo improves common-mode rejection ratio (CMRR)
Four-wire serial control port interface:
Simple interface with microprocessor or DSP serial port
Supports daisy-chain connection of multiple PGA2500 devices
Dedicated input pin for selecting unity gain
Overload output pin provides clipping indication
Four general-purpose digital output pins
Requires ±5V power supply
Available in SSOP-28 package
PGA2500IDB Applications
Microphone preamplifiers and mixers
Digital mixers and recorders
