Commodity Model:LT3598EUF

Trade Name:LED Driver

Brand:ADI

Particular Year:21+

Package:QFN-24

Delivery Date:New and Original

Stock: 5000pcs

Quantity:
Online Inquiry

Contacts:

E-Mail:

Contact Number:

Corporate Name:

Product Parameters

Manufacturer
ADI
Model
LT3598EUF
Package
QFN-24
Describe
6-series 30mA LED driver with 1.5% current matching accuracy

Product Description

The LT3598EUF is a high-efficiency, multi-channel LED driver IC in a 24-pin QFN (4mm × 4mm) package, ideal for high-precision backlighting and display applications. The chip uses a boost topology to drive up to 6 strings of LEDs, with each string capable of delivering up to 30mA of current, and features ±1.5% current matching accuracy to ensure uniform LED brightness.


Product Attributes — LT3598EUF

Product Type: LED Lighting Driver IC

Series: LT3598

Mounting Style: SMD/SMT

Package/Case: QFN-24

Number of Outputs: 6 Outputs

Output Current: 30 mA

Input Voltage - Maximum: 30 V

Input Voltage - Minimum: 3.2 V

Topology: Boost

Operating Frequency: 200 kHz to 2.5 MHz

Output Voltage: 44 V

Minimum Operating Temperature: -40°C

Maximum Operating Temperature: +125°C


Key Features

High-precision current regulation

±1.5% LED current matching ensures uniformity of display backlighting.

Supports PWM and analogue dimming, with a dimming ratio of up to 3000:1 (PWM) and 10:1 (analogue).

Wide input voltage range

3.2 V to 30 V input, suitable for single-cell lithium batteries, 12 V/24 V industrial power supplies, and other applications.

Output voltage up to 44 V, capable of driving multiple series-connected LEDs.

Programmable switching frequency

Supports adjustable frequencies from 200kHz to 2.5MHz, can synchronise with an external clock, and optimises EMI design.

Comprehensive protection features

Open-circuit LED protection (OPENLED alarm)

Overvoltage protection (OVP)

Temperature derating control (to prevent LED overheating).

Low-power design

Extremely low standby current (<1μA), suitable for battery-powered devices.


Applications — LT3598EUF

Laptop computer displays

Mid-sized displays

Automotive liquid crystal displays

Associated Products

Model

Brand

Package

Quantity

Describe

LP5030RJVR

TI

VQFN-46

12000

30-Channel I2C Constant Current RGB LED Driver

ADP8861ACPZ

ADI

LFCSP-20

3000

7-Channel Intelligent LED Driver, LFCSP-20

LP5892QRRFRQ1

TI

VQFN-76

3000

Automotive high current 48x16 LED matrix driver with 16-bit PWM dimming and ultra low power consumption

MAX25608CAUI

ADI

TSSOP-EP-28

2000

12-Switch, High Brightness LED Matrix Manager for Automotive Front Lights

LT3755EMSE-2

ADI

MSOP16

20000

LED Driver IC 1 Output DC DC Controller Flyback, SEPIC, Buck, Boost Analog, PWM Dimming 16-MSOP-EP

MAX25608EAUI

Maxim

TSSOP-28

3000

12 Switches, LED Matrix Manager, TSSOP-28

TLC59731DR

TI

SOIC-8

10000

3-Channel, 8-Bit, PWM LED Driver with Single Bus Interface

NCL30186DDR2G

ON

SOIC-10

5000

LED Drivers for LED Lighting

TLD2314EL

INFINEON

SSOP-14

7500

LED Driver IC 3 Output Linear Dimming 120mA PG-SSOP-14-5

TPS92601BQPWPRQ1

TI

HTSSOP-20

3000

Automotive Dual Channel Automotive Headlight LED Driver, HTSSOP-20
