IXFP14N85XM is a high-performance N-channel enhancement-mode power MOSFET belonging to the Ultra-Junction X-Class series. This device is designed for high-voltage and high-current applications, featuring low on-resistance (Rds(on)) and excellent thermal performance, making it suitable for applications such as power management, industrial control, electric vehicles (EV), and renewable energy systems.

IXFP14N85XM Product Features

High voltage withstand capability: Maximum drain-source voltage (Vds) of 850V, suitable for high-voltage applications.

Low on-resistance: Rds(on) of 0.42Ω @ Vgs=10V, reducing power loss during conduction.

High current handling capability: Maximum drain current (Id) of 14A, meeting high power density design requirements.

Low Gate Charge: Qg is 62nC, optimising switching performance and reducing energy loss during switching.

Excellent Thermal Performance: Uses a TO-220 package, providing good heat dissipation performance.

Wide Operating Temperature Range: -55°C to 150°C, suitable for various industrial and automotive applications.

IXFP14N85XM Product Attributes

Manufacturer:    IXYS

Product Type:    MOSFET

Technology:    Si

Mounting Style:    Through Hole

Package/Case:    TO-220-3

Transistor Polarity: N-Channel

Number of Channels: 1 Channel

Vds - Drain-Source Breakdown Voltage: 850 V

Id - Continuous Drain Current: 14 A

Rds On - Drain-Source On-Resistance: 550 mOhms

Vgs - Gate-Source Voltage: -30 V, +30 V

Vgs th - Gate-Source Threshold Voltage:    3.5 V

Qg - Gate Charge:    30 nC

Minimum Operating Temperature:    -55°C

Maximum Operating Temperature:    +150°C

Pd - Power Dissipation:    460 W

Channel Mode:    Enhancement

Trademark Name:    HiPerFET

Application Scope

IXFP14N85XM is widely used in power electronic systems requiring high voltage, high efficiency, and high reliability, including but not limited to:

Industrial power supplies: As the main switching element, it provides efficient power conversion capability.

Uninterruptible power supplies (UPS): Ensures the stability and reliability of power supply.

Photovoltaic inverters: Used for DC-AC conversion to achieve efficient output of solar energy.

Electric vehicle charging systems: Its high voltage withstand capability and low on-resistance make it an ideal power switching device.

Motor drives: Such as variable frequency drives (VFDs) and servo drives in industrial automation equipment.

Power adapters: Suitable for high-performance laptop power adapters and server power systems.
