This STL135N8F7AG N-channel power MOSFET, featuring STripFET™ F7 technology, has an enhanced trench gate structure with extremely low on-resistance, and also reduces internal capacitance and gate charge for faster, more efficient switching.

STL135N8F7AG Features

Designed for Automotive Applications and AEC-Q101 Qualified

One of the lowest RDS (on-state) devices on the market

Excellent FoM (factor of merit)

Low Crss/Ciss ratio for EMI immunity

High avalanche ruggedness

Wettable side package

STL135N8F7AG Technical Data

FET Type: N-Channel

Technology: MOSFET (metal oxide)

Drain-Source Voltage (Vdss): 80 V

Current at 25°C - Continuous Drain (Id): 130A (Tc)

Drive voltage (max. Rds On, min. Rds On): 10V

On-resistance (max) at different Id, Vgs: 3.6 mOhm @ 13A, 10V

Vgs(th) at different Id (max): 4.5V @ 250µA

Gate Charge (Qg) (Max) at Vgs: 103 nC @ 10 V

Vgs (max): ±20V

Input capacitance (Ciss) at varying Vds (max): 6800 pF @ 40 V

Power Dissipation (Max): 4.8W (Ta), 135W (Tc)

Operating Temperature: -55°C ~ 175°C (TJ)

Grade: Automotive Grade

Qualification: AEC-Q101

Mounting Type: Surface Mount, Wettable Sides

Supplier Device Package: PowerFlat™ (5x6)

Package/Housing: 8-PowerVDFN

STL135N8F7AG Applications

Switching Applications
