IXFH150N17T2 is 175V 150A N-Channel enhancement power MOSFET transistors.

Specifications Of IXFH150N17T2

FET Type:N-Channel

Technology:MOSFET (Metal Oxide)

Drain to Source Voltage (Vdss):175 V

Current - Continuous Drain (Id) @ 25°C:150A (Tc)

Drive Voltage (Max Rds On, Min Rds On):10V

Rds On (Max) @ Id, Vgs:12mOhm @ 75A, 10V

Vgs(th) (Max) @ Id:4.5V @ 1mA

Gate Charge (Qg) (Max) @ Vgs:233 nC @ 10 V

Vgs (Max):±20V

Input Capacitance (Ciss) (Max) @ Vds:14600 pF @ 25 V

Power Dissipation (Max):880W (Tc)

Operating Temperature:-55°C ~ 175°C (TJ)

Features Of IXFH150N17T2

High Current Handling Capability

Fast Intrinsic Diode

Dynamaic dv/dt Rated

Avalanche Rated

Low RDS(on)

Advantages Of IXFH150N17T2

Easy to Mount

Space Savings

High Power Density

Applications Of IXFH150N17T2

DC-DC Converters

Battery Chargers

Switch-Mode and Resonant-Mode Power Supplies

DC Choppers

AC Motor Drives

Uninterruptible Power Supplies

High Speed Power Switching Applications
