Trade Name:Diode
Brand:IXYS
Particular Year:22+
Package:TO-263
Delivery Date:New and Original
Stock: 2400pcs
DSEI36-06AS-TRL is a fast recovery rectifier diode (FRED) in a TO-263-3 (D²Pak) surface mount package with a single diode structure, designed for applications requiring fast reverse recovery, such as high-frequency switching power supplies, PFC boost, UPS, inverters, and motor drives.
DSEI36-06AS-TRL Features/Advantages:
Planar passivated chip
Low leakage current
Extremely short recovery time
Improved thermal performance
Extremely low Irm value
Extremely gentle recovery characteristics
Breakdown voltage rating ensures reliable operation
Gentle reverse recovery characteristics reduce electromagnetic interference (EMI)/radio frequency interference (RFI)
Low Irm value reduces:
- Power loss within the diode
- Conduction loss in the switching device
DSEI36-06AS-TRL Product Attributes:
Technology: Standard
Voltage - DC Reverse (Vr) (Max): 600 V
Current - Average Rectified (Io): 37A
Voltage - Forward (Vf) at different If: 1.6 V @ 37 A
Speed: Fast recovery ≤ 500 ns, > 200 mA (Io)
Reverse recovery time (trr): 50 ns
Current - Reverse leakage at different Vr: 100 µA @ 600 V
Mounting Type: Surface Mount
Package/Case: TO-263-3, D2PAK (2 leads + tab), TO-263AB
Supplier Device Package: TO-263AA
Operating Temperature - Junction: -40°C to 150°C
DSEI36-06AS-TRL Applications:
High-frequency anti-parallel diode
Switching equipment
Anti-saturation diode
Buffer diode
Free-wheeling diode
Rectifier in Switching Mode Power Supply (SMPS)
Uninterruptible Power Supply (UPS)
