Service Telephone:86-755-83294757
Trade Name:N-channel MOSFET
Brand:IXYS
Particular Year:23+
Package:TO-252-3
Delivery Date:New and Original
Stock: 5000pcs
The IXTY02N120P-TRL is an N-channel MOSFET introduced by IXYS, packaged in a TO-252-3 (DPAK) package, suitable for high-voltage switching, power management, and industrial control applications. This device features a 1200V breakdown voltage and a 200mA continuous drain current, utilising metal-oxide semiconductor technology to provide low on-resistance and fast switching performance, making it suitable for high-voltage, low-current power conversion circuits.
IXTY02N120P Product Attributes
Product Type: MOSFET
Technology: Si
Mounting Style: SMD/SMT
Package/Case: DPAK-3 (TO-252-3)
Transistor Polarity: N-Channel
Number of Channels: 1 Channel
Vds - Drain-Source Breakdown Voltage: 1.2 kV
Id - Continuous Drain Current: 200 mA
Rds On - Drain-Source On-Resistance: 75 Ohms
Vgs - Gate-Source Voltage: - 20 V, + 20 V
Minimum Operating Temperature: - 55°C
Maximum Operating Temperature: + 150°C
Pd - Power Dissipation: 33 W
IXTY02N120P Features
International standard packaging
Dynamic dv/dt rating
Low RDS(on) and Qg
Avalanche rating
Low package inductance
IXTY02N120P Applications
DC-DC converters
Battery chargers
Switch-mode and resonant-mode power supplies
Lighting ballasts
AC and DC motor drivers
Robotics and servo control
Laser drivers
