Commodity Model:ADL5535ARKZ

Trade Name:RF Amplifiers

Brand:ADI

Particular Year:25+

Package:SOT-89-3

Delivery Date:New and original

Stock: 3000pcs

Quantity:
Online Inquiry

Contacts:

E-Mail:

Contact Number:

Corporate Name:

Product Parameters

Manufacturer
ADI
Model
ADL5535ARKZ
Package
SOT-89-3
Describe
Rf amplifier 20 MHz to 1.0 GHz intermediate frequency gain module

Product Description

The ADL535ARKZ is a 15 dB linear amplifier with a maximum operating frequency of up to 1 GHz. This device can be used in various cellular, cable television (CATV), military and instrumentation equipment. Its main features include:

Fixed gain: 16 dB

Operating frequency range: 20 MHz to 1.0 GHz

The input and output are internally matched at 50 Ω

Integrated bias control circuit

OIP3:

45.5 dBm (190 MHz)

45.5 dBm (380 MHz)

P1dB: 18.9 dBm (190 MHz)

Noise coefficient

At 190 MHz, 3.2 dB

At 380 MHz, 3.3 dB

5V single power supply

Low quiescent current: 97 mA

MSL-1 grade SOT-89 package

ESD rated value: ±2 kV (Class 2)

Compatible with the 20 dB gain ADL5536 pin


Among the existing internal matching IF gain modules, the ADL5535ARKZ offers the highest dynamic range. This performance can be achieved by simultaneously providing an extremely low noise figure and very high OIP3 characteristics throughout the entire 1 GHz frequency range. The ADL5535ARKZ also offers an extremely flat gain and P1dB throughout the entire frequency range, and it does not change with temperature, power supply or device variations.


Youdaoplaceholder0 Application fields ‌

The ADL535ARKZ is widely used in various cellular, cable television (CATV), military and instrumentation equipment.
