The ADM6319B31ARJZ is a power monitoring circuit designed to monitor the supply voltage and code execution integrity of microprocessor systems. The on-chip watchdog timer not only provides a power-on reset signal but also resets the microprocessor if it fails to issue a strobe pulse within a preset timeout period. The reset signal can also be initiated externally via a manual reset input pin.

The ADM6319B31ARJZ is housed in a 5-pin SOT-23 package and features a typical power consumption of just 3 μA, making it suitable for low-power, portable applications.

ADM6319B31ARJZ Features

26 reset threshold options

2.5 V to 5 V (in 100 mV increments)

4 reset timeout options

1 ms, 20 ms, 140 ms, 1120 ms (minimum)

4 watchdog timeout options

6.3 ms, 102 ms, 1600 ms, 25.6 s (typical)

Manual reset input

Reset output stage

Push-pull low-active

Open-drain low-active

Push-pull high-active

Low power consumption: 5 μA

Guaranteed reset output active (VCC = 1 V)

Supply glitch immunity

Rated for industrial temperature range

5-pin SOT-23 package

ADM6319B31ARJZ Applications

Microprocessor systems

Computers and controllers

Intelligent instruments

Portable devices
