ADL5542ACPZ: RF Amplifier - 20 dB Fixed Gain, 50 MHz to 6 GHz RF/IF Gain Module

Product Details:

Model: ADL5542ACPZ

Package: LFCSP-8

Type: RF Amplifier -RF/IF Gain Module

The ADL5542ACPZ are wideband 20dB linear amplifiers that operate up to 6GHz and can be used in a wide variety of CATV, cellular, and instrumentation equipment.

The ADL5542ACPZ provides 20dB of gain that is stable over frequency, temperature, and power supply fluctuations with good device uniformity. At up to 6 GHz, the device is internally matched to a 50 Ω resistor with an input return loss of 10 dB or less. External operation requires only input/output AC coupling capacitors, power supply decoupling capacitors, and external inductive devices.

The ADL5542ACPZ is manufactured using the InGaP HBT process with an ESD rating of 1 kV (Class 1C). The 3 mm × 3 mm LFCSP package provides exposed pads to reduce thermal resistance.

ADL5542ACPZ Product Features:

20 dB fixed gain

Operating frequency up to 6 GHz

Inputs/outputs internally matched to 50 Ω resistors

Integrated bias control circuitry

Outputs IP3

46 dBm at 500 MHz

40 dBm at 900 MHz

Output 1 dB compression point: 20.6 dB at 900 MHz

Noise index of 3 dB at 900 MHz

Single 5V power supply

Small 8-pin LFCSP package

Pin-compatible with ADL5541 with 15dB gain

ESD rated to 1kV (Class 1C)
