The HMC747LC3CTR is a D-type flip-flop designed to support data transfer rates up to 13 Gbps and clock frequencies up to 13 GHz. During normal operation, data is transferred to the output on the rising edge of the clock. Inverting the clock input enables negative edge triggering applications. The HMC747LC3CTR also provides an output level control pin, VR, which may be utilised for loss compensation or signal level optimisation.

All input and output signals of the HMC747LC3CTR are terminated at 50 Ω to the on-chip Vcc and support either AC or DC coupling. Inputs and outputs may be directly connected to a 50 Ω Vcc-terminated system, whilst DC-blocking capacitors may be employed if 50 Ω termination to ground is employed. The HMC747LC3CTR operates from a single +3.3V DC supply and is available in a RoHS-compliant 3x3 mm SMT ceramic package.

HMC747LC3CTR Specifications

Differential and single-ended operation

Fast rise and fall times: 22/20 ps

Low power consumption: 264 mW (typical)

Programmable differential

Output voltage swing: 700 - 1,300 mV

Propagation delay: 105 ps

Single supply: +3.3V

16-pin 3x3mm SMT package: 9mm²

HMC747LC3CTR Applications

RF ATE applications

Broadband test and measurement

Serial data transfer rates up to 13 Gbps

Digital logic systems up to 13 GHz
