The LTC3854EMSE is a high-performance synchronous buck switching DC/DC controller designed to drive a fully N-channel synchronous power MOSFET stage.

The LTC3854EMSE employs a 400kHz fixed-frequency current-mode architecture. It operates from an input voltage range of 4.5V to 38V (absolute maximum of 40V) and regulates output voltages from 0.8V to 5.5V.

The RUN/SS pin provides soft-start and enable functionality. The use of OPTI-LOOP compensation enables optimised transient response across a wide range of output capacitance and ESR values. During short-circuit conditions, the current foldback feature limits MOSFET thermal dissipation. This current foldback feature is disabled during soft-start.

The LTC3854EMSE features a minimum on-time of 75ns, making it highly suitable for high step-down ratios. The integrated robust MOSFET driver permits the use of high-power external MOSFETs to deliver output currents up to 20A.

LTC3854EMSE Product Attributes

Product Type: Switching Regulator

Mounting Style: SMD/SMT

Package/Case: MSOP-12

Topology: Buck

Output Voltage: 800 mV to 5.5 V

Output Current:    25 A

Number of Outputs:    1 Output

Input Voltage - Min:    4.5 V

Input Voltage - Max:    38 V

Switching Frequency:    400 kHz

Minimum Operating Temperature:    -40°C

Maximum Operating Temperature:    +85°C

Series:    LTC3854

Input Voltage:    4.5 V to 38 V

Load Regulation:    0.1 %

Operating Supply Current:    2 mA

LTC3854EMSE Applications

Automotive Systems

Telecommunications Systems

Industrial Equipment

Distributed DC Power Systems
