ADSP-21489BSWZ-4B is a high-performance fourth-generation digital signal processor (DSP) within the SHARC® series. This processor is specifically designed for applications requiring high computational capability and efficient signal processing, making it suitable for automotive audio, industrial control, and medical applications.

Specifications

Core clock speed: 400 MHz

Core Voltage: 1.10V

I/O Voltage: 3.30V

Operating Temperature Range: -40°C to +85°C

Package Type: 176-pin LQFP (24mm x 24mm with heat sink)

Mounting Type: Surface Mount

On-chip RAM: 5 Mbit

Peripheral Interfaces:

16-bit wide SDR SDRAM external memory interface

Digital Application Interface (DAI), including 1 S/P DIF Tx/Rx and 1 8-channel asynchronous sample rate converter

8 serial ports (SPORT) supporting I2S, left-aligned sample pairs, DSP serial, and TDM modes

2 SPI-compatible ports supporting master and slave modes

UART and two-wire interface

16 pulse width modulation (PWM) channels

3 full-featured timers

Additional features:

FIR, IIR, and FFT accelerators

Comprehensively enhanced DMA engine, including scatter/gather DMA and delay-line DMA

Application Domains

The ADSP-21489BSWZ-4B finds extensive application in the following domains:

Industrial control: such as motor drives, servo control, PLCs (programmable logic controllers), etc.

Car audio: for in-vehicle infotainment systems.

Medical applications: such as ultrasound imaging, patient monitors, and electrocardiogram analysis equipment.

Communication systems: such as base station transceivers, routers, and packet processing units in switches.

Consumer electronics: such as high-end audio systems, video surveillance devices, and smart home controllers.
