The ISO7221ADR is a dual-channel digital isolator with capacitive coupling (SiO₂ barrier) technology that provides electrical isolation up to 2500Vrms for high reliability scenarios such as industrial automation, medical equipment, and automotive electronics. The device supports 1Mbps data rate with low propagation delay (475ns) and excellent interference immunity (25kV/µs CMTI) to ensure signal transmission stability and safety.

ISO7221ADR Product Features

High Isolation Performance

Isolation voltage: 2500Vrms (according to UL 1577), transient immunity up to 25kV/µs, effective suppression of common mode noise.

Silicon dioxide (SiO₂) isolation gate is used to ensure long-term reliability and aging resistance1.

High speed and low latency

1Mbps data transfer rate for industrial communication buses (e.g. Modbus, Profibus).

Propagation delay of only 475ns and pulse width distortion (PWD) of up to 14ns ensure signal integrity.

Wide Voltage and Low Power Consumption

Operating voltage range: 3V~5.5V, compatible with 3.3V and 5V systems.

Typical power consumption as low as 2.5mW for battery powered devices.

High Reliability Design

Conforms to AEC-Q100 automotive grade standards with an operating temperature range of -40°C~125°C.

Integrated 4kV ESD protection for enhanced system robustness.

Compact package: SOIC-8 package (3.9mm x 4.9mm) for high density PCB layout.

ISO7221ADR Applications

- Factory automation

- Modbus

- Modbus

- DeviceNet™ data bus

- Computer Peripheral Interface

- Server Control Interface

- Data Acquisition
