Service Telephone:86-755-83294757
Trade Name:Digital Isolator
Brand:ADI
Particular Year:23+
Package:SOIC-16
Delivery Date:New and Original
Stock: 13000pcs
The ADUM1401CRWZ is a four-channel digital isolator with 3/1 channel directionality, utilising ADI's iCoupler® technology. These isolators integrate high-speed CMOS with single-chip air-core transformer technology, offering superior performance characteristics compared to alternative devices such as optocouplers.
ADUM1401CRWZ Features
Automotive version certified to AEC-Q100
Low power consumption
Bidirectional communication
3 V/5 V level conversion
Operating temperature up to: 125 °C
High data rate: dc to 90 Mbps (NRZ)
Precision timing characteristics
High common-mode transient immunity: >25 kV/μs
ADUM1401CRWZ Product Attributes
Product Type: Digital Isolator
Series: ADUM1401
Mounting style: SMD/SMT
Package/housing: SOIC-16
Number of channels: 4 channels
Polarity: Unidirectional
Data rate: 120 Mb/s
Insulation voltage: 2500 Vrms
Isolation type: Magnetic coupling
Supply voltage - maximum: 5.5 V
Minimum Supply Voltage: 2.7 V
Operating Supply Current: 31 mA, 57 mA
Propagation Delay Time: 27 ns
Minimum Operating Temperature: -40°C
Maximum Operating Temperature: +105°C
Maximum Fall Time: 3 ns (Typ)
Maximum Rise Time: 3 ns (Typ)
Operating Power Supply Voltage: 5 V
Pulse Width: 1000 ns
ADUM1401CRWZ Applications
General-purpose multi-channel isolation
SPI interface/data converter isolation
RS-232/RS-422/RS-485 transceiver
Industrial fieldbus isolation
Automotive systems
