ISO7341FCDWR is a four-channel digital isolator in a 16-SOIC package, supporting high-speed data transmission at 25Mbps and providing 3000Vrms (1 minute) electrical isolation. This device is based on capacitive coupling technology and is suitable for applications requiring high noise suppression and signal isolation, such as industrial automation, motor control, power management, and communication equipment.

Features of ISO7341FCDWR

High isolation performance

3000Vrms isolation voltage (compliant with UL 1577 standard).

25kV/µs common-mode transient immunity (CMTI), suitable for strong electromagnetic interference (EMI) environments.

High-speed data transmission

25Mbps data rate, suitable for digital interfaces such as RS-485, CAN, and SPI.

Low propagation delay (58 ns) ensures real-time signal transmission.

Multi-channel configuration

4 isolated channels (3 forward/1 reverse), supporting flexible signal transmission directions.

Wide operating voltage range

3 V to 5.5 V power supply, compatible with 3.3 V/5 V systems, suitable for various application scenarios.

Low power consumption design

Typical operating current of 7.8 mA, optimising system energy efficiency.

Key parameters of ISO7341FCDWR

Package: 16-SOIC (7.5mm wide)

Isolation voltage: 3000Vrms

Data rate: 25Mbps

Propagation delay: 58ns (maximum)

Rise/fall time: 2.1ns / 1.7ns (typical)

Operating temperature: -40°C to +125°C

Number of channels: 4 (3 forward/1 reverse)

Common-mode transient immunity: 25kV/µs

Supply voltage: 3V to 5.5V

Applications of ISO7341FCDWR

• Replaces optocouplers in the following applications:

– Industrial fieldbus (Fieldbus)

– Profibus fieldbus

– Modbus

– DeviceNet data bus

– Server control interface

– Motor control

– Power supply

– Battery pack
