Trade Name:Digital Isolators
Brand:TI
Particular Year:24+
Package:SOIC-8
Delivery Date:New and Original
Stock: 5000pcs
The ISO7220CDR devices are dual-channel digital isolators. For ease of PCB layout, the channels are orientated in the same direction in the ISO7220x and in opposite directions in the ISO7221x. These devices have logic input and output buffers that are isolated by TI's Silicon Dioxide (SiO2) barrier, providing VDE-compliant galvanic isolation up to 4000VPK. When used with isolated power supplies, these devices block high voltages and isolated grounds, and prevent noise currents on data buses or other circuits from going to local ground or interfering with or damaging sensitive circuits.
The binary input signal is conditioned and converted to a balanced signal, which is then differentiated by an isolation layer. Across this isolation layer, the differential comparator can receive logic conversion information and then set or reset the flip-flop and output circuitry accordingly. The circuit will send periodic update pulses across the isolation layer to verify that the DC output level is normal. If this DC refresh pulse is not received every 4µs, the input is considered to be unpowered or not actively driven, and the fail-safe circuitry will drive the output to a logic high state.
ISO7220CDR Features
Product Category: Digital Isolators
Series: ISO7220C
Mounting Style: SMD/SMT
Package / Case: SOIC-8
Number of Channels: 2 Channel
Polarity: Unidirectional
Data rate: 25 Mb/s
Isolation Voltage: 2500 Vrms
Isolation Type: Capacitive Coupling
Supply Voltage - Max: 5 V
Supply Voltage - Min: 2.8 V
Operating supply current: 4 mA, 20 mA
Propagation delay time: 32 ns
Minimum operating temperature: - 40 C
Maximum operating temperature: + 125 C
Forward channels: 2 Channel
Operating supply voltage: 2.8 V to 5 V
ISO7220CDR Applications
- Factory automation
- Modbus
- Modbus
- DeviceNet™ data bus
- Computer Peripheral Interface
- Server Control Interface
- Data Acquisition
Model
Brand
Package
Quantity
Describe
TI
SOIC-8
5000
I2C Digital Isolator 2500 Vrms 2 Channels 1 Mbps 25 kV/µs CMTI 8-SOIC (0.154", 3.90 mm wide)
TI
SOIC-16
6000
RS422, RS485 Digital Isolator 2500 Vrms 3 Channels 40 Mbps 25 kV/µs CMTI 16-SOIC (0.295", 7.50 mm wide)
ADI
SOIC-16
6000
I2C Digital Isolator 5000 Vrms 2 Channels 1 Mbps 25 kV/µs CMTI 16-SOIC (0.295", 7.50 mm wide)
Skyworks
SOIC-16
15000
General Purpose Digital Isolator 5000 Vrms 6 Channels 150 Mbps 35 kV/µs CMTI 16-SOIC (0.295", 7.50 mm wide)
TI
SOIC-16
12000
Low power consumption, four channels, 3/1, 25Mbps, default output low level digital isolator
