Service Telephone:86-755-83294757
Trade Name:Digital Isolator
Brand:Skyworks
Particular Year:22+
Package:SOIC-16
Delivery Date:New and Original
Stock: 15000pcs
The SI8660BD-ASR is a high-performance six-channel digital isolator belonging to the Si86xx series, packaged in a 16-SOIC package, and suitable for applications requiring high-voltage isolation, such as industrial automation, electric vehicles, medical equipment, and communication systems. This device is based on capacitive coupling isolation technology, offering 5kVrms isolation voltage and 150Mbps high-speed data transmission, with low propagation delay, high noise immunity, and low power consumption characteristics, making it a suitable replacement for traditional optocoupler isolation solutions.
SI8660BD-ASR Features
High isolation performance: 5kVrms isolation voltage (compliant with UL, CSA, and VDE standards).
Common-mode transient immunity (CMTI): 35kV/µs (minimum), suitable for high-noise environments.
High-speed data transmission: 150Mbps data rate, supporting isolation of digital signals such as PWM, SPI, and I²C.
Propagation delay: 13 ns (maximum), pulse width distortion: 4.5 ns (maximum), ensuring signal integrity.
Operating voltage: 2.5V to 5.5V, compatible with multiple MCU interfaces.
Low static current, optimised for energy efficiency.
Operating temperature: -40°C to +125°C, suitable for harsh environments.
Compliant with AEC-Q100 automotive-grade certification (select models), suitable for automotive electronics.
Compact packaging: 16-SOIC (7.5mm width), ideal for high-density PCB layouts.
SI8660BD-ASR Typical Applications
Industrial automation (PLC, servo drives, isolated ADC/DAC)
Electric vehicles (BMS, charging stations, traction inverters)
Power management (isolated DC-DC, photovoltaic inverters)
Communication equipment (RS-485, CAN isolation)
Medical electronics (patient monitoring, medical power supplies)
