The LTC3880IUJ is a dual-output Polyphase DC/DC synchronous buck switch mode regulator controller featuring an I²C-based serial interface compatible with PMBus. The controller employs a constant-frequency current-mode architecture, supported by the LTpowerPlay™ software development tool with a graphical user interface (GUI).

Switching frequency, output voltage, and device address are programmable via external configuration resistors. Parameters may be set through the digital interface or stored in EEPROM. Voltage, current, internal/external temperature, and fault status can be read back via the bus interface. The LTC3880IUJ incorporates a 5V linear regulator.

LTC3880IUJ Applications

High-current distributed power systems

Telecommunications, data communications and storage systems

Intelligent energy-saving power regulation

LTC3880IUJ Features

PMBus/I²C-compatible serial interface

Telemetry readback including VIN, IIN, VOUT, IOUT, temperature and faults

Programmable voltage, current limit, digital soft start/stop, timing control, margin adjustment, OV/UV and frequency synchronisation (250kHz to 1MHz)

Output voltage accuracy of ±0.5% over the entire temperature range

Integrated 16-bit ADC

Internal EEPROM with ECC and fault logging

Integrated high-performance N-channel MOSFET gate driver

Power Conversion

Wide VIN range: 4.5V to 24V

VOUT range: 0.5V to 5.4V (at VOUT0 = 4V)

Analogue current-mode control loop

Precise PolyPhase® current sharing for up to 6 phases

40-pin (6mm × 6mm) QFN package

Compliant with AEC-Q100 standards for automotive applications
