Trade Name:Low-dropout Regulators
Brand:ADI
Particular Year:22+
Package:DFN-12
Delivery Date:New and Original
Stock: 2500pcs
LT1763CDE-2.5 is a low-noise, low-power linear regulator belonging to the LT1763 series. Featuring high performance, low quiescent current, and low voltage drop, this regulator is suitable for a variety of low-power applications.
LT1763CDE-2.5 Specifications
Input voltage range: 1.8V to 20V
Output voltage: Fixed 2.5V
Maximum Output Current: 500mA
Maximum Voltage Drop: 0.45V @ 500mA
Quiescent Current: 30μA
Operating Temperature Range: -40°C to +125°C
Package Type: 12-pin leadless quad flat no-lead package (3x4mm DFN)
PSRR/Ripple Rejection: 65dB (typical)
Noise: 20μVRMS (10Hz to 100kHz)
Protection Features: Overcurrent Protection, Over-Temperature Protection, Reverse Battery Protection
LT1763CDE-2.5 Features
Low Noise: 20μVRMS (10Hz to 100kHz)
Output Current: 500mA
Low Quiescent Current: 30μA
Wide input voltage range: 1.8V to 20V
Low dropout voltage: 300mV
Extremely low shutdown current: < 1μA
No protection diode required
Fixed output voltages: 1.5V, 1.8V, 2.5V, 3V, 3.3V, 5V
Adjustable output range: 1.22V to 20V
Stabilisation achievable with 3.3μF output capacitor
Stabilisation achievable with aluminium, tantalum or ceramic capacitors
Reverse battery protection
No reverse current
Overcurrent and over-temperature protection
LT1763CDE-2.5 Applications
Cellular telephones
Battery-powered systems
Noise-sensitive instrumentation systems
