The LTC3789EGN is a high-performance buck-boost switching regulator controller capable of operation when the input voltage is higher than, lower than, or equal to the output voltage. Employing a constant frequency, current mode architecture, the device provides a phase-locked frequency up to 600kHz, whilst an output current feedback loop enables support for battery charging. With a wide input and output range of 4V to 38V (maximum 40V) and seamless, low-noise transitions between operating regions, the LTC3789 is an ideal choice for automotive, telecommunications and battery-powered systems.

The controller's operating mode is determined via the MODE/PLLIN pin. This pin selects between pulse-skipping mode and forced continuous mode operation, and permits synchronisation of the IC to an external clock. Pulse-skipping mode achieves low ripple under light load conditions, whilst forced continuous mode operates at a fixed frequency to satisfy noise-sensitive applications.

A power good output pin provides an indication when the output is within 10% of its design setpoint. The LTC3789EGN is available in a low-profile, 28-pin narrow SSOP package.

LTC3789EGN Applications

Automotive systems

Distributed DC power systems

High-power battery-powered equipment

Industrial control

LTC3789EGN Product Attributes

Manufacturer:    Analog Devices Inc.

Product Type:    Switching Regulator

Mounting Style:    SMD/SMT

Package/Enclosure:    SSOP-28

Topology:    Boost, Buck

Output Voltage:    800 mV to 38 V

Output Current:    10 A

Number of Outputs:    1 Output

Input Voltage - Minimum:    4 V

Input Voltage - Maximum:    38 V

Quiescent Current:    40 μA

Switching Frequency:    200 kHz to 600 kHz

Minimum Operating Temperature:    -40°C

Maximum Operating Temperature:    +125°C

Series:    LTC3789

Input Voltage:    15 V

Load Regulation:    0.01%

Operating Supply Current:    3 mA
