The TPS5402DR is a high-efficiency, low-power asynchronous buck DC-DC converter with a wide input voltage range (3.5V to 28V) and a maximum output current of 1.7A. It is housed in an 8-pin SOIC package, suitable for surface mount applications.

TPS5402DR Key Features

Wide input voltage range: 3.5V to 28V

High output current: up to 1.7A

Adjustable output voltage: the output voltage can be adjusted between 0.8V and 26.04V via an external resistor divider

Fixed-frequency control: Switching frequency can be adjusted between 50kHz and 1.1MHz, with frequency spreading to reduce electromagnetic interference (EMI)

Light-load mode: Automatically enters pulse-skipping mode under light loads to reduce power consumption

Protection features: Includes cycle-by-cycle current limiting, overvoltage protection, and short-circuit protection

Operating temperature range: -40°C to 85°C

TPS5402DR Product Attributes

Product Type: Switching Regulator

Mounting Style: SMD/SMT

Package/Enclosure: SOIC-8

Topology: Buck

Output Voltage: 800 mV

Output Current: 1.7 A

Number of Outputs: 1 Output

Input Voltage - Minimum: 3.5 V

Input Voltage - Maximum:    28 V

Quiescent Current:    100 uA

Switching Frequency:    50 kHz to 1.1 MHz

Minimum Operating Temperature:    -40°C

Maximum Operating Temperature:    +125°C

Series:    TPS5402

TPS5402DR Application Scope

Consumer electronics: such as home appliances, set-top boxes, LCD displays, peripherals, and battery chargers.

Industrial applications: such as industrial control systems and automotive entertainment system power supplies.

5V, 9V, 12V, and 24V distributed power systems.
