Commodity Model:TPS561208DDCR

Trade Name:Synchronous Buck Converter

Brand:TI

Particular Year:22+

Package:SOT-23-6

Delivery Date:New and Original

Stock: 12000pcs

Quantity:
Online Inquiry

Contacts:

E-Mail:

Contact Number:

Corporate Name:

Product Parameters

Manufacturer
TI
Model
TPS561208DDCR
Package
SOT-23-6
Describe
4.5V to 17V input, 1A output, synchronous buck converter

Product Description

The TPS561208DDCR is a simple, easy-to-use 1A synchronous buck converter in an SOT-23 package.


The TPS561208DDCR device is optimised to operate with as few external components as possible and achieves low standby current.


These switch-mode power supply (SMPS) devices utilise D-CAP2 mode control, providing fast transient response and supporting low equivalent series resistance (ESR) output capacitors such as specialised polymer capacitors and ultra-low ESR ceramic capacitors without the need for external compensation components.


The TPS561208DDCR is available in a 6-pin 1.6 × 2.9 (mm) SOT package, with a rated junction temperature range of –40°C to 125°C.


 Features

• 1A converter with integrated 140mΩ and 84mΩ FETs

• {1}D-CAP2{2} mode control for fast transient response

• Input voltage range: 4.5V to 17V

• Output voltage range: 0.76V to 7V

• Continuous current mode

• 580kHz switching frequency

• Low shutdown current (less than 10µA)

• 2% feedback voltage accuracy (25°C)

• Starts from pre-biased output voltage

• Cycle-by-cycle overcurrent limit

• Intermittent mode overcurrent protection

• Non-latching under-voltage protection (UVP) and thermal shutdown (TSD) protection

• Fixed soft-start: 1.0ms


TPS561208DDCR Parameters

Input voltage range: 4.5V to 17V

Output voltage range: 0.76V to 7V (adjustable)

Output current: 1A (maximum)

Switching frequency: 580kHz (fixed)

Quiescent current: 400μA (typical)

Operating temperature: -40°C to +125°C (TJ)

Synchronous rectification: Yes


TPS561208DDCR Applications

• Digital TV power supplies

• High-definition Blu-ray™ disc players

• Networked home terminal devices
