The MP8765GQ-Z is a fully integrated high-frequency synchronous rectification buck switch mode converter. It offers a highly compact solution that delivers 6A continuous output current over a wide input voltage range, with excellent load and line regulation performance.

The MP8765GQ-Z operates at high efficiency across a wide output current load range. The constant on-time (COT) control mode enables fast transient response and simplifies loop stabilization. The under-voltage lockout is internally set to 4.6 V, and an open-drain power good signal indicates that the output voltage is within the rated range. Comprehensive protection features include overcurrent protection (OCP) and thermal shutdown.

The MP8765GQ-Z converter requires minimal external components and is available in a QFN16 (3mm × 3mm) package.

MP8765GQ-Z Product Features and Benefits

Wide operating input voltage range: 5V to 24V

Continuous output current: 6A

Selectable PWM/PFM mode

Integrated low on-resistance power MOSFET

Proprietary switch loss reduction technology

Reference voltage: 1%

7ms internal soft start

Output discharge function

Switching frequency: 500kHz

Burst mode overcurrent protection (OCP) and over-temperature shutdown protection

Automatic retry overvoltage protection (OVP)

Adjustable output voltage range: 0.604V to 5.5V

Package: QFN-16 (3×3mm), surface mount type (SMT)

Operating temperature: -40°C to +125°C (TJ), suitable for harsh environments

MP8765GQ-Z Application Areas

Laptops

Tablets

Network systems

Personal video recorders

Flat-panel TVs and displays

Distributed power systems
