Service Telephone:86-755-83294757
Trade Name:Synchronous Buck Converter
Brand:TI
Particular Year:21+
Package:WSON-8
Delivery Date:New and Original
Stock: 2000pcs
The TPS62161DSGR is a synchronous buck DC-DC converter that uses DCS-Control™ topology technology and is suitable for high power density applications. The device has a wide input voltage range of 3V to 17V, supports a continuous output current of 1A, and provides a fixed output voltage of 1.8V (some versions can be adjusted to 0.9V to 6V). Its switching frequency reaches up to 2.25MHz, enabling the use of smaller inductors and optimising PCB space utilisation.
Features of the TPS62161DSGR
• DCS-Control™ topology technology
• Input voltage range: 3V to 17V
• Output current up to 1A
• Adjustable output voltage range: 0.9V to 6V
• Fixed output voltage version
• Seamless power-saving mode transition
• Typical quiescent current: 17µA
• Normal power supply output
• 100% duty cycle mode
• Short-circuit protection
• Over-temperature protection
• Pin-compatible with TPS62170 and TPS62125
• Packaged in a 2.00mm × 2.0mm 8-pin wafer-level small outline no-lead (WSON) package
Technical specifications of the TPS62161DSGR
Topology: Buck
Output voltage: 1.8 V
Output current: 1 A
Number of outputs: 1 Output
Input voltage - minimum: 3 V
Input Voltage - Maximum: 17 V
Quiescent Current: 268 uA
Switching Frequency: 2.25 MHz
Minimum Operating Temperature: -40°C
Maximum Operating Temperature: +125°C
Series: TPS62161
Applications of the TPS62161DSGR
• Standard 12V rail-mounted power supply
• Point-of-load (POL) power supply powered by a single or multiple lithium-ion batteries
• Low-dropout regulator (LDO) replacement
• Embedded systems
• Digital cameras, digital camcorders
• Mobile computers, tablets, modems
