Trade Name:Synchronous Step-down Converter
Brand:TI
Particular Year:22+
Package:WSON-10
Delivery Date:New and Original
Stock: 12000pcs
The LM53601MQDSXRQ1 is an automotive-grade synchronous buck switch mode regulator in a 10-WSON (3×3mm) package, designed for automotive electronics, industrial control, and high-efficiency power management applications. This device features a wide input voltage range, high switching frequency, and low quiescent current, making it suitable for applications such as ADAS, body electronics, and infotainment systems.
LM53601MQDSXRQ1 Features
Wide input voltage range: 3.55V to 36V (transient voltage withstand 42V), suitable for automotive battery voltage fluctuations.
High-efficiency synchronous rectification: 1A output current, efficiency >90%, reducing thermal management requirements.
Fixed switching frequency: 2.1MHz, supporting high-frequency designs and reducing external component sizes.
Low-power mode: static current as low as 23µA, shutdown current 1.8µA, optimising battery life.
Adjustable/fixed output: 3.3V, 5V, or adjustable (3.3V to 6V), flexibly adapting to different load requirements.
Automotive-grade reliability: AEC-Q100 Grade 1 certified, operating temperature -40°C to 150°C (TJ).
LM53601MQDSXRQ1 Parameters
Topology: Buck
Output voltage: 3.3 V to 6 V
Output current: 1 A
Number of output terminals: 1 Output
Input Voltage - Minimum: 3.55 V
Input Voltage - Maximum: 36 V
Quiescent Current: 23 uA
Switching Frequency: 2.1 MHz
Minimum Operating Temperature: -40°C
Maximum Operating Temperature: +150°C
LM53601MQDSXRQ1 Applications
• Automotive camera applications
• Automotive driver assistance systems
• Automotive body applications
