The LMR33620BRNXR SIMPLE SWITCHER regulator is a simple and easy-to-use synchronous buck DC/DC converter that delivers excellent efficiency and is suitable for demanding industrial applications. The LMR33620BRNXR can drive up to 2A of load current using an input voltage of up to 36V, and offers excellent light-load efficiency and output accuracy in an ultra-small solution size. Features such as a power good indicator and a precise enable pin help enable flexible and user-friendly solutions suitable for a wide range of applications. The LMR33620BRNXR automatically folds back the frequency under light load conditions to improve efficiency. This device eliminates most external components through integrated technology and features a pinout designed for simple PCB layout. Protection features include thermal shutdown, input under-voltage lockout, cycle-by-cycle current limiting, and intermittent short-circuit protection.

The LMR33620BRNXR is available in an 8-pin HSOIC package and a 12-pin 3mm × 2mm next-generation VQFN package with wettable sides. The device also offers a version compliant with the AEC-Q100 standard.

Features of the LMR33620BRNXR

• Specifically designed for harsh industrial applications

– Input voltage range: 3.8V to 36V

– Output voltage range: 1V to 24V

– Output current: 2A

– Peak current mode control

– Very short on-time, only 68ns

– Frequency: 400kHz, 1.4MHz, 2.1MHz

– Junction temperature range: –40°C to +125°C

– Low EMI and low switching noise

– Integrated compensation network

• Low EMI and switching noise

– HotRod™ package

– Parallel input current paths

• Efficient power conversion under all load conditions

– Peak efficiency > 95%

– Operating quiescent current as low as 25µA

• Flexible system interface

– Power good status flag and precision enable pin

LMR33620BRNXR Key Parameters

Input voltage range: 3.8V to 36V

Output voltage range: 1V to 24V (adjustable)

Output current: 2A (continuous)

Switching frequency: 400kHz / 1.4MHz / 2.1MHz (selectable)

Quiescent current: 25µA (operating mode)

Package: 12-VQFN-HR (3×2mm)

Operating temperature: -40°C to +125°C (junction temperature)

Applications of the LMR33620BRNXR

• Motor drive systems: drones, AC inverters, variable frequency drives, servo systems

• Factory and building automation systems: PLC CPUs, HVAC control, elevator control

• General-purpose wide input voltage power supplies
