TPS563201DDCR: Synchronous Buck Converter with Eco-mode, SOT-23-6

Overview:

The TPS563201DDCR is an easy-to-use 3A synchronous buck converter in a small form factor transistor (SOT)-23 package. These switched-mode power supply (SMPS) devices feature a D-CAP2 control topology to provide fast transient response and support low equivalent series resistance (ESR) output capacitors such as dedicated polymers and ultra-low ESR ceramic capacitors without the need for external compensation components.

Basic Information:

Model No.: TPS563201DDCR

Package: SOT-23-6

Type: Synchronous Buck Converter

Frequency - Switch: 580kHz

Voltage - Input (Min): 4.5V

Voltage - Input (Max): 17V

Voltage - Output (Min/Fixed): 0.768V

Voltage - Output (Max): 7V

Current - Output: 3A

Operating Temperature: -40°C ~ 125°C (TJ)

TPS563201DDCR Product Features:

3A converter with integrated 95mΩ and 57mΩ FETs

D-CAP2™ control scheme for fast transient response

Input voltage range: 4.5V to 17V

Output voltage range: 0.76V to 7V

Pulse hopping mode

580kHz switching frequency

Low shutdown current (less than 20µA)

2% feedback voltage accuracy (25°C)

Start-up from pre-biased output voltage

Cycle-by-cycle overcurrent limiting

Intermittent mode overcurrent protection

Non-latching UVP and TSD protection

Fixed soft start: 1.0ms

TPS563201DDCR Applications:

Digital TV power supplies

HD Blu-ray™ disc players

Networked home terminal equipment

Digital set-top boxes (STBs)

Security monitoring
