The ISO7721QDRQ1 device is a high-performance dual-channel digital isolator that provides a 3000VRMS isolation rating compliant with the UL 1577 standard. The ISO7721QDRQ1 device features enhanced insulation ratings compliant with VDE, CSA, TUV, and CQC standards.

ISO7721QDRQ1 Features

• Meets automotive application requirements

• Meets the following results in accordance with the AEC-Q100 standard:

– Device temperature grade 1: –40°C to +125°C operating temperature range

– Device HBM ESD classification grade 3A

– Device CDM ESD classification grade C6

• Functional safety type

– Documentation available for functional safety system design: ISO7720-Q1, ISO7721-Q1

• 100Mbps data rate

• Robust and reliable isolation barrier:

– Expected lifespan exceeding 30 years at 1.5 kVRMS operating voltage

– Isolation rating up to 5000VRMS

– Surge capability up to 12.8kV

– CMTI typical value of ±100kV/μs

• Wide power supply voltage range: 2.25V to 5.5V

• 2.25V to 5.5V level conversion

• Default output high level (ISO772x) and low level (ISO772xF) options

• Low power consumption, typical current per channel at 1 Mbps is 1.7 mA

• Low propagation delay: 11 ns (typical)

• Excellent electromagnetic compatibility (EMC)

– System-level ESD, EFT, and surge immunity

– ±8kV IEC 61000-4-2 contact discharge protection across the isolation barrier

– Low electromagnetic interference (EMI)

• Narrow-body SOIC (D-8) package

ISO7721QDRQ1 Applications

• Hybrid, electric, and powertrain systems (EV/HEV)

– Battery management system (BMS)

– On-board charger

– Traction inverter

– DC/DC converter

– Inverter and motor control
