FAN8811MNTXG - High-Frequency, High Side and Low Side Gate Driver

Product Overviews

FAN8811MNTXG is high side and low side gate−drive IC designed for high−voltage, high−speed, driving MOSFETs operating up to 80 V. The FAN8811 integrates a driver IC and a bootstrap diode. The driver IC features low delay time and matched PWM input propagation delays, which further enhance the performance of the part.

FAN8811 - Simplified Block Diagram:

Key Features

• Drives two N−Channel MOSFETs in High & Low Side

• Integrated Bootstrap Diode for High Side Gate Drive

• Bootstrap Supply Voltage Range up to 100 V

• 3 A Source, 6 A Sink Output Current Capability

• Drives 1 nF Load with Typical Rise/Fall Times of 6 ns/4 ns

• TTL Compatible Input Thresholds

• Wide Supply Voltage Range 7.5 V to 16 V

(Absolute Maximum 18 V)

• Fast Propagation Delay Times (Typ. 30 ns)

• 2 ns Delay Matching (Typical)

• Under−Voltage Lockout (UVLO) Protection for Drive Voltage

• Operating Junction Temperature Range of −40°C to 125°C

Typical Applications

• Power Supplies for Telecom and Datacom

• Half−Bridge and Full−Bridge Converters

• Synchronous−Buck Converters

• Two−Switch Forward Converters

• Class−D Audio Amplifiers
