Commodity Model:VN7140AJTR

Trade Name:High-side Driver

Brand:ST

Particular Year:23+

Package:PowerSSO-16

Delivery Date:New and Original

Stock: 30000pcs

Quantity:
Online Inquiry

Contacts:

E-Mail:

Contact Number:

Corporate Name:

Product Parameters

Manufacturer
ST
Model
VN7140AJTR
Package
PowerSSO-16
Describe
High-side driver with MultiSense analogue feedback for automotive applications

Product Description

The VN7140AJTR is a high-side driver from STMicroelectronics featuring MultiSense analogue feedback functionality, specifically designed for automotive applications. The product is manufactured using STMicroelectronics' proprietary VIPower™ M0-7 technology and is packaged in a PowerSSO-16 package.


VN7140AJTR Features

Advanced protection features: Integrated load current limiting, active overload management, over-temperature shutdown, and configurable latch-off functionality.

Fault reset functionality: Unlocks the output or disables the latch function during a fault via the FaultRST pin.

Multi-Function Analogue Output Pins: Provides high-precision proportional load current sensing, power supply voltage feedback, and chip temperature sensing functions, while detecting overload, short circuit to ground, short circuit to VCC, and open-load conditions during shutdown.

Sensing Enable Pin: Allows disabling shutdown diagnostics in the module's low-power mode and sharing external sensing resistors between similar devices.

Automatic restart and status flag: Supports automatic restart functionality and status flag.


Specifications

Model: VN7140AJTR

Package: PowerSSO-16 (16-Pin LFSOP)

Input voltage range: 4V to 28V

Output current (maximum): 8A

On-resistance: 140mΩ (typical)

Input Type: Non-inverting

Switch Type: General-purpose

Operating Temperature: -40°C to +150°C (TJ)

Protection Features: Current limiting, open-circuit detection, over-temperature, over-voltage, UVLO


VN7140AJTR Applications

• Suitable for various automotive resistive, inductive, and capacitive loads

• Specifically designed for automotive signal lights (supports R10W or LED rear combination lights)

• Used for protective power supply in ADAS systems: radar and sensors
