NCP4318ALCDR2G: Dual-channel synchronous rectification (SR) controller for LLC resonant converters, SOIC-8

Product Details:

Model: NCP4318ALCDR2G

Package: SOIC-8

Type: Synchronous rectification controller

Overview:

The NCP4318ALCDR2G is a hybrid-mode synchronous rectification (SR) controller for LLC resonant converters, utilising instantaneous drain voltage and prior dead-time information whilst requiring a minimal number of external components. Adaptive dead-time control compensates for parasitic inductance voltage, maximising SR MOSFET conduction and efficiency. Multi-step shutdown threshold control and SR current reversal detection prevent reverse current during fast load transients, ensuring stable SR operation across the entire load range. Furthermore, to enhance efficiency at light loads, the VGATE voltage can adaptively reduce from 10V to 6V/5V.

NCP4318ALCDR2G Specifications:

Application: Resonant converter controller

Supply voltage: 0V to 35V

Supply current: 8mA

Operating temperature: -40°C to 125°C (T_J)

Mounting type: Surface mount

Package/case: 8-SOIC (0.154", 3.90mm width)

Supplier device package: 8-SOIC

NCP4318ALCDR2G Applications:

LLC resonant PSU

High power density adapters

Large screen LED-TV and OLED-TV power supplies

High efficiency desktop and server power supplies

Network and telecommunications power supplies

High power LED lighting
