The VN5E160STR is a single-channel high-side driver manufactured using ST's proprietary VIPower M0-5 technology, housed in an ultra-compact SO-8 package.

The VN5E160STR is specifically designed for driving automotive ground-connected loads, offering protection and diagnostic features, and supporting seamless 3V and 5V CMOS-compatible interfaces with any microcontroller.

The device integrates advanced protection features, including load current limiting, active management of surges and overloads via power limiting, over-temperature shutdown with automatic restart, and active overvoltage clamping.

Each output channel is associated with a dedicated low-level active digital status pin to provide enhanced diagnostic functions, including rapid detection of overloads and ground shorts, over-temperature indication, VCC short-circuit diagnosis, and open-load on/off status detection.

By pulling up the STAT_DIS pin, the diagnostic feedback for the entire device can be disabled, enabling wired or connected operation with other similar devices.

VN5E160STR All Features:

General Features: Active management of startup current via power limiting, extremely low standby current, 3.0V CMOS-compatible inputs, optimised electromagnetic radiation, extremely low electromagnetic sensitivity, compliant with the 2002/95/EC European Directive

Protection features: Undervoltage shutdown, overvoltage clamping, load current limiting, fast thermal transient self-limiting protection, ground loss and VCC loss protection, over-temperature shutdown with automatic restart (thermal shutdown), reverse polarity battery protection (a), electrostatic discharge protection

Diagnostic functions: Open-drain status output, on-state open-load detection, off-state open-load detection, output short-circuit to VCC detection, overload and short-circuit to ground (power limit) indication, thermal shutdown indication

VN5E160STR Key parameters:

Load voltage: 4.5 V – 28 V

Continuous output current: 7 A (peak 10 A)

On-resistance: 160 mΩ (typical)

Protection functions: Current limiting, over-temperature shutdown (with self-recovery), over-voltage clamping, short-circuit to ground and short-circuit to VCC detection

Diagnostic Output: Open-drain STAT pin, supports open-load detection and ON/OFF status detection

Logic Interface: 3.3 V / 5 V CMOS compatible

Operating Junction Temperature: –40 °C to +150 °C

Package: 8-SOIC, surface mount

VN5E160STR Applications: Suitable for various resistive, inductive, and capacitive loads.
