The NCP1252EDR2G is a current-mode PWM controller suitable for both forward and flyback applications. It provides all the functionality required to build efficient and reliable AC-DC switching power supplies, particularly well-suited for ATX power supplies. Packaged in an SOIC-8 format, it saves PCB space and is the preferred solution for cost-sensitive projects.

NCP1252EDR2G Specifications

Manufacturer: ON Semiconductor

Product Type: Switching Controller

Topology: Flyback, Forward

Mounting Style: Surface Mount

Number of Outputs: 1 Output

Package/Case: SOIC-8

Switching Frequency - Maximum: 500 kHz

Duty Cycle - Maximum: 45.6%

Input Voltage: 9V to 28V

Operating Supply Voltage: 9V to 28V

Output Voltage: 12V

Output Current: 800 mA

Operating Temperature Range: -40°C to +125°C

NCP1252EDR2G Features

Peak current mode control

Adjustable switching frequency

Primary-side overcurrent protection with latch, 10ms fixed delay

Adjustable soft-start timer

Auto-recovery under-voltage detection

Vcc range extended up to 28V with auto-recovery UVLO

Internal 160ns leading edge blanking

Frequency jitter

Adjustable internal slope compensation

+500mA/-800mA sink/source drive capability

Cycle-skipping operation under light/no load

SOIC-8 package

NCP1252EDR2G Applications

Personal computer silver box power supplies

AC-DC adaptor converters

Gaming console adaptors

Flyback and forward applications
