Commodity Model:VN5T016AHTR

Trade Name:High-side Driver

Brand:ST

Particular Year:22+

Package:TO-252-6

Delivery Date:New and Original

Stock: 5000pcs

Quantity:
Online Inquiry

Contacts:

E-Mail:

Contact Number:

Corporate Name:

Product Parameters

Manufacturer
ST
Model
VN5T016AHTR
Package
TO-252-6
Describe
Single-channel high-side driver with current sensing support for 24V automotive applications

Product Description

VN5T016AHTR is STMicroelectronics' single-channel high-side driver, featuring VIPower™ technology, suitable for driving resistive or inductive loads. The chip supports analogue current sensing, providing a current output proportional to the load current. It also includes multiple protection features, such as overload protection, over-temperature protection, and overvoltage protection, ensuring safe operation under fault conditions.


VN5T016AHTR Product Features

Analogue current sensing: Provides a current output proportional to the load current, enabling real-time monitoring.

High-side drive: Suitable for applications requiring high-side switching.

Multiple protection features: Includes overload protection, over-temperature protection, and overvoltage protection, enhancing system reliability.

Wide operating voltage range: 8V to 36V, suitable for various power supply environments.

High reliability: Operating temperature range of -40°C to 150°C (TJ), suitable for harsh environments.

Low on-resistance: 16 milliohms (typical), reducing power consumption.

High output current: Maximum output current of 43A.


VN5T016AHTR Product Attributes

Number of outputs: 1

Ratio - Input:Output: 1:1

Output configuration: High-side

Output type: N-channel

Interface: On/Off

Voltage - Load: 8V to 36V

Voltage - Power supply (Vcc/Vdd): Not required

Current - Output (Maximum): 43A

On-Resistance (Typical): 16 mΩ

Input Type: Non-Inverting

Fault Protection: Current limiting (fixed), open-load detection, over-temperature, over-voltage

Operating Temperature: -40°C to 150°C (TJ)

Mounting Type: Surface Mount

Supplier Device Package: HPAK


VN5T016AHTR Application Areas

Automotive Electronics: Suitable for high-side drive applications in automobiles, such as motor control and lighting control.

Industrial Control: Can be used for load driving in industrial automation equipment.

Communication Systems: Suitable for communication devices requiring high reliability and precise control.
