The DRV8871DDARQ1 device is a brush-type DC motor driver for printers, appliances, industrial equipment, and other small machines. Two logic inputs control the H-bridge driver, which consists of four N-channel metal-oxide-semiconductor field-effect transistors (MOSFETs) capable of bi-directionally controlling the motor at peak currents up to 3.6A. Motor speed can be controlled by pulse-width modulation (PWM) of the inputs using a current-decay mode. If both inputs are set low, the motor driver enters a low-power sleep mode.

The DRV8871DDARQ1 devices feature advanced current regulation circuitry that does not use an analogue voltage reference or external sense resistors. This new solution uses standard low-cost, low-power resistors to set the current threshold. The device's ability to limit current to a known level significantly reduces system power requirements and eliminates the need for large capacitors to maintain a stable voltage, especially during motor startup and stall.

The device provides comprehensive protection against faults and short-circuit problems, including under-voltage lockout (UVLO), over-current protection (OCP) and thermal protection (TSD). The device will automatically return to normal operation after the fault is removed.

Features

- Certified for automotive electronics applications

- The following AEC-Q100-compliant results are available:

- Device Temperature Level 1: -40°C to +125°C ambient operating temperature range

- Device Human Body Model (HBM) Electrostatic Discharge (ESD) Classification Level 2

- Device Component Charging Mode (CDM) ESD Classification Level C4B

- H-Bridge Motor Drivers

- Drives a DC motor, a stepper motor winding, or other loads

- 6.8V to 45V Wide operating voltage range

- 565mΩ (typical) RDS(on) (HS + LS)

- 3.6A peak current drive capability

- PWM control interface

- Current regulation without sense resistor

- Low power sleep mode

- Small Package Size

- 8-pin HSOP with PowerPAD™

- 4.9mm × 6mm

- Integrated Protection Features

- VM undervoltage lockout (UVLO)

- Overcurrent protection (OCP)

- Thermal shutdown (TSD)

- Automatic fault recovery

Applications

- Automotive infotainment

- HUD Projector Adjustment

- Motorised shift knob

- On-board charger
