L9997ND013TR is an automotive-grade motor driver IC designed specifically for brushed DC motors. It features high integration and outstanding performance, providing precise motor control and drive functionality suitable for a wide range of automotive applications.

Product Features — L9997ND013TR

High Integration: Integrates control and power stage circuits, simplifying system design.

Multiple Protection Features: Includes over-temperature protection, short-circuit protection, and under-voltage lockout, ensuring reliable operation under various operating conditions.

Low Power Consumption Design: Features low static current, helping to reduce system energy consumption.

Meets automotive-grade standards: Complies with AEC-Q100 standards, with an operating temperature range of -40°C to +150°C, meeting the stringent requirements of automotive environments.

Half-bridge output configuration: Features two half-bridge outputs, capable of driving dual motors or single motors in both forward and reverse directions.

Product Parameters — L9997ND013TR

Output Configuration: Half-bridge (2)

Interface: Parallel

Technology: CMOS, DMOS

Output current: 1.2A

Supply voltage: 7V to 16.5V

Operating temperature: -40°C to 150°C (TJ)

Mounting type: Surface mount

Package/housing: 20-SOIC (0.295", 7.50mm wide)

Supplier device package: 20-SO

Application Areas — L9997ND013TR

Automotive Electronics: Widely used in automotive window lifters, seat adjustment motors, sunroof motors, and other systems, providing precise motor control.

Industrial Automation: Suitable for controlling small DC motors in industrial equipment, such as motor drives in automated production lines.

Consumer Electronics: Ideal for consumer electronics requiring small motor drives, such as power tools and home appliances.
