The UCC28881DR is a high-performance offline PWM controller chip developed by Texas Instruments, specifically designed for flyback, buck, and buck-boost topologies, and suitable for low-power AC-DC converters. The chip integrates a 700V MOSFET and is packaged in an SOIC-7 package, featuring extremely low static current (<100μA) and high energy efficiency, making it suitable for applications such as chargers, adapters, and LED driver power supplies.

Features (UCC28881DR)

• Integrated 14Ω, 700V power MOSFET

• Integrated high-voltage current source for internal device bias power supply

• Integrated current sensing

• Internal soft-start

• Self-biased switch (starts and operates directly on rectified mains voltage)

• Supports buck, buck/boost, and flyback topologies

• Device static current <100μA

• Provides stable current protection during load circuit short circuits

• Protection

– Current limit protection

– Overload and output short-circuit protection

– Over-temperature protection

• Package and operating conditions

– Package: SOIC-7 (7-pin)

– Operating temperature: -40°C to +125°C (junction temperature)

Applications (UCC28881DR)

• AC-DC power supplies (non-isolated buck converters with output currents up to 225mA in continuous conduction mode (CCM) and 150mA in discontinuous conduction mode (DCM))

• Electricity meters, home automation switch-mode power supplies (SMPS)

• Bias power supplies for devices supporting microcontrollers (MCU), radio frequency (RF), and Internet of Things (IoT)

• Home appliances, large home appliances, and light-emitting diode (LED) drivers
