Trade Name:Motor Driver
Brand:ST
Particular Year:19+
Package:SO-24
Delivery Date:New and Original
Stock: 3600pcs
The L6229D is a DMOS fully integrated 3-phase motor driver with overcurrent protection.
Realized in BCD technology, the device combines isolated DMOS power transistors with CMOS and bipolar circuits on the same chip.
The device includes all the circuitry needed to drive a 3-phase BLDC motor including: a 3-phase DMOS bridge, a constant off time PWM current controller and the decoding logic for single ended Hall sensors that generates the required sequence for the power stage.
Available in SO24 (20 + 2 + 2) packages, the L6229D features a non-dissipative overcurrent protection on the high-side power MOSFET and thermal shutdown.
L6229D Features
• Operating supply voltage from 8 to 52 V
• 2.8 A output peak current (1.4 A DC)
• RDS(ON) 0.73 Ω typ. value at Tj = 25 °C
• Operating frequency up to 100 kHz
• Non-dissipative overcurrent detection and protection
• Diagnostic output
• Constant tOFF PWM current controller
• Slow decay synchronous rectification
• 60° and 120° Hall effect decoding logic
• Brake function
• Tachometer output for speed loop
• Cross conduction protection
• Thermal shutdown
• Undervoltage lockout
• Integrated fast free wheeling diodes
L6229D Application
• Factory automation end-points
• Home appliances
• Small pumps
• ATMs
Model
Brand
Package
Quantity
Describe
TI
HTQFP-48
9000
Maximum 45V three-phase smart gate driver with current shunt amplifier and SPI
INFINEON
LQFP-64
3000
PMSM/BLDC motor & PFC controller with additional 32-bit microcontroller
